| LED Lamp Parameters | |
| Type | SMD1010 3 in 1 LED |
| Arrangement | 1R1G1B |
| Chip Parameters | Red (620-625nm), Green (520-525nm), Blue (470-475nm) |
| LED Module Specs | |
| Pixel Pitch | 1.667mm |
| Module Size | 200mm × 150mm |
| Module Resolution | 120 × 90 = 10800 Dots |
| Max Power Dissipation | ≤18W |
| LED Cabinet Specs | |
| Cabinet Resolution | 240 × 180 (Dots) |
| Cabinet Dimension | 400mm × 300mm × 70mm |
| Cabinet Material | Iron / Pressure Casted Aluminum / Aluminum Profiles |
| Weight | 3.83KG ± 0.05KG |
| Technical Parameters | |
| Visual Angle | Horizontal 160° / Vertical 140° |
| Brightness | 97% Adjustment |
| Life-span | 100,000 hours |
| Refresh Rate | Constant Current Drive, 1/30 scans |
| Display Ability | 2K HD, 4K UHD |
1. Free Training: Technical training is provided for engineers, covering operation and maintenance of the LED display. Instruction manuals, software, and test reports are included.
2. Installation Support: We can provide engineering assistance for installation via air travel or guide you remotely using Team-viewer control.
3. Rapid Response: Our team will reply to any product inquiries within 24 hours to provide effective solutions.
